FNQ-R-1-3/10 - Eaton Bussmann Class CC Time Delay Fuse 1.3A 600V 200kA Interrupt Rating

FNQ-R-1-3/10

FNQ-R-1-3/10 is an Eaton Bussmann Class CC time delay fuse designed for advanced circuit protection in control transformers and industrial applications.FNQ-R-1-3/10 features a 1.3 ampere rating, 600 volts AC voltage rating, and a 200kA interrupting rating, providing reliable current limitation and protection against short-circuit events. This fuse is a rejection type that fits standard and rejection-style holders, offering time-delay characteristics suitable for high inrush currents while complying with NEC and UL standards.

Key Specifications
• Amperage: 1.3 A
• Voltage Rating: 600 VAC
• Interrupt Rating: 200,000 A (200kA)
• Fuse Type: Class CC, Time Delay
• Mounting Type: Rejection style fuse, fits standard holders
• Series/Frame: Bussmann FNQ-R Limitron
• Dimensions: Approx. 1.5 inches length
• Application: Control circuit transformer protection
• Certifications: Meets NEC Section 110.9 and UL requirements
• Current Limitation: Provides 10X better current limitation

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FNQ-R-1-3/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : CC-Tron
• Type : FNQ
• Voltage : 600
• Amperage : 1.3
• AIC rating : 200kA@600V
• Diameter : 0.41
• Class Rating : CC
• Barrels : 1

Product Data

• UPC : 051712147040
• GTIN : 00051712147040
• Country of Origin : Mexico
• Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.015
• Certification : CE/UL-248-4 Guide JDDZ/CSA Class 1422-01
