FNQ-30 - Eaton Bussmann 30A 500V Time-Delay Midget Fuse, 10kA Interrupt Rating

FNQ-30

FNQ-30 is a 30 ampere, 500 volt time-delay midget fuse from Eaton Bussmann designed for motor control transformers and circuits with inrush currents.FNQ-30 features a fiber tube cartridge body with nickel-plated brass endcaps, providing a high interrupting rating of 10,000 amperes at 500 VAC. It is a dual element fuse with time-delay characteristics, suitable for protecting circuits requiring reliable overload and short circuit protection.

Key Specifications
• Amperage: 30 A
• Voltage Rating: 500 V AC
• Interrupt Rating: 10 kA at 500 VAC
• Fuse Type: Time-Delay (Dual Element)
• Series: FNQ
• Mounting Type: Fuse holder mounting with clip termination
• Physical Size: 13/32 in diameter x 1-1/2 in length
• Construction: Fiber tube with nickel-plated brass endcaps
• Application: Motor control transformers, circuits with inrush currents
• Certifications: UL Listed, CSA Recognized
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: FNQ-30
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FNQ Series
• Type : FNQ
• Voltage : 500
• Amperage : 30
• AIC rating : 10kA@500V
• Diameter : 0.41
• Barrels : 1



Product Data

• UPC : 051712786768
• GTIN : 00051712786768
• Country of Origin : Mexico
• Dimensions : 0.41 in x 1.5 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.175
• Certification : CE, CSA Class 1422-01, UL-248-14 Guide JDYX
