FNQ-2-1/4 - Eaton Bussmann 2.25A 600V Class CC Time Delay Fuse

FNQ-2-1/4

FNQ-2-1/4 is a 2.25 ampere, 600 volt Class CC time delay fuse from Eaton Bussmann designed for branch circuit and industrial control protection.FNQ-2-1/4 features a melamine tube construction with dual element time delay characteristics, providing reliable current limiting and protection with a high interrupting rating of 200kA at 600Vac. It is a non-indicating fuse with ferrule end x ferrule end termination suitable for use in fuse blocks and holders compatible with Class CC fuses.

Key Specifications
• Amperage: 2.25 A
• Voltage Rating: 600 Vac
• Fuse Type: Time Delay (Dual Element)
• Series: FNQ-R (Class CC)
• Interrupting Rating: 200,000 AIC at 600 Vac
• Mounting Type: Ferrule end x ferrule end
• Construction: Melamine tube
• Poles: Single pole
• Certifications: UL Listed, CSA Certified, RoHS Compliant
• Trip Characteristics: 12 seconds at 200% rated current

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FNQ-2-1/4
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FNQ Series
• Type : FNQ
• Voltage : 500
• Amperage : 2
• AIC rating : 10kA@500V
• Diameter : 0.41
• Barrels : 1

Product Data

• UPC : 051712786256
• GTIN : 00051712786256
• Country of Origin : Mexico
• Dimensions : 0.41 in x 1.5 in x 0.41 in (Length/Depth x Height x Width)
• Weight : 0.175
• Certification : CE, CSA Class 1422-01, UL-248-14 Guide JDYX
