Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FNM-40
FNM-40 is a Bussmann Series FNM time-delay supplemental fuse designed for circuits with high inrush currents such as motor and transformer loads. This fuse provides reliable protection up to 250V AC and features a dual element design for enhanced performance in demanding applications. The FNM-40 fuse features a melamine tube construction with nickel-plated bronze endcaps and a ferrule end configuration for secure mounting. It is color-coded green for easy identification of its 250V AC maximum voltage rating. This fuse is ideal for supplemental protection in inductive circuits and is RoHS compliant.
- 40 A amperage rating
- 250 V AC maximum voltage
- Dual element design
- Ferrule end x ferrule end
- Time-delay (slow blow) fuse type
- Interrupt rating: 10 kA at 125 V AC
- Mounting style: Holder
- Series: Bussmann Series FNM
- RoHS compliant
- Color coded green for 250V AC
- Body style: Cylindrical cartridge
- Non-indicating
Specifications
- Part Number: FNM-40
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FNM Series
- Type : FNM
- Voltage : 32
- Amperage : 40
- AIC rating : 10kA@250V
- Connection : Ferrule Non-Rejection
- Diameter : 0.41
- Class Rating : 1422-01
- Barrels : 1
- Velocity : TD - Time Delayed
Product Data
- UPC : 051712523028
- GTIN : 00051712523028
- Country of Origin : Mexico
- Dimensions : 0.39 in x 1.44 in x 0.39 in (Length/Depth x Height x Width)
- Weight : 0.2
- Certification : CE, CSA Class 1422-01, UL-248-14 Guide JDYX
