FNM-3/10 - Bussmann 3/10 Amp 250V Time-Delay Midget Fuse 13/32 x 1-1/2 Inch 35AIC

FNM-3/10

FNM-3/10 is a Bussmann 3/10 Amp, 250 Volt AC time-delay midget fuse designed for supplemental protection in inductive circuits.This fuse features a cylindrical body measuring 13/32 inch diameter by 1-1/2 inch length, with a dual element for time-delay operation. It has an interrupting rating of 35 amperes at 250 VAC and 10,000 amperes at 125 VAC, meeting UL 248-14 and CSA Class 1422-01 certifications. The FNM series is RoHS compliant and suitable for use in recommended fuse holders and blocks.

• Amperage: 0.3 Amp (3/10 Amp)
• Voltage Rating: 250 VAC
• Fuse Type: Time-Delay Midget
• Body Size: 13/32 inch diameter x 1-1/2 inch length
• Interrupting Rating: 35 AIC @ 250 VAC, 10,000 AIC @ 125 VAC
• Element: Dual
• Certifications: UL Listed, CSA Certified, RoHS Compliant
• Mounting: Fuse holders/blocks compatible with 13/32 x 1-1/2 size
• Class: Supplemental protection for inductive circuits

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FNM-3/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FNM Series
• Type : FNM
• Voltage : 250
• Amperage : 3
• AIC rating : 100kA@250V
• Connection : Ferrule Non-Rejection
• Diameter : 0.41
• Class Rating : 1422-01
• Barrels : 1

Product Data

• UPC : 051712520034
• GTIN : 00051712520034
• Country of Origin : Mexico
• Dimensions : 0.39 in x 1.44 in x 0.39 in (Length/Depth x Height x Width)
• Weight : 0.2
• Certification : CE, CSA Class 1422-01, UL-248-14 Guide JDYX
