Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FNM-12
FNM-12 is an Eaton Bussmann series time-delay midget fuse rated for 12 amperes and 250 volts AC with dual elements for superior protection.FNM-12 features a 10 kA interrupt rating at 250 VAC, nickel-plated bronze endcaps, and ferrule end x ferrule end connections. It is a non-indicating fuse designed for superior overload and cycling capabilities, compliant with CE and RoHS standards.
- Amperage: 12 A
- Voltage Rating: 250 V AC
- Interrupt Rating: 10 kA at 250 VAC
- Fuse Type: Time-Delay Dual Element
- Connection: Ferrule end x ferrule end
- Material: Nickel-plated bronze endcaps
- Physical Size: 1.5 in length, 0.41 in width and height
- Non-indicating fuse
- Certifications: CE Marked, RoHS Compliant
- Series: Eaton Bussmann FNM
Specifications
- Part Number: FNM-12
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FNM Series
- Type : FNM
- Voltage : 250
- Amperage : 12
- AIC rating : 10kA@250V
- Connection : Ferrule Non-Rejection
- Diameter : 0.41
- Class Rating : 1422-01
- Barrels : 1
Product Data
- UPC : 051712521208
- GTIN : 00051712521208
- Country of Origin : Mexico
- Dimensions : 1.5 in x 0.41 in x 0.41 in (Length/Depth x Height x Width)
- Weight : 0.2
- Certification : CE, CSA Class 1422-01, UL-248-14 Guide JDYX
