FNA-5-6/10 - Eaton Bussmann Series 5.6A 250VAC Time-Delay Supplemental Fuse

FNA-5-6/10

FNA-5-6/10 is a Eaton Bussmann Series 5.6 ampere, 250 VAC time-delay supplemental fuse designed for reliable circuit protection.This fuse features a dual-element, time-delay design suitable for inductive and electronic load circuits, providing excellent protection against inrush currents. It has a cylindrical 13/32 inch by 1-1/2 inch form factor with pin indication for visual open fuse status. Rated for 5.6 amps and 250 volts AC, it offers a high interrupt rating of 200 kA at 250 VAC and 10 kA at 125 VAC. The fuse is UL and CSA certified and designed for use in supplemental fuse blocks and holders.

• Current Rating: 5.6 Amps
• Voltage Rating: 250 VAC
• Fuse Type: Time-Delay (Dual-Element)
• Interrupt Rating: 200 kA at 250 VAC, 10 kA at 125 VAC
• Dimensions: 13/32 inch x 1-1/2 inch
• Pin Indicating for visual fuse status
• Mounting Type: Fuse Cartridge
• Series: Bussmann FNA
• Certifications: UL, CSA
• Application: Inductive and electronic load circuits

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FNA-5-6/10
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FNA Series
• Type : FNA
• Voltage : 125
• Amperage : 5
• AIC rating : 10kA@125V
• Diameter : 0.41
• Class Rating : Midget
• Barrels : 1

Product Data

• UPC : 05171271359
• GTIN : 00051712713597
• Dimensions : 1.5 in x 0.406 in x 0.406 in (Length/Depth x Height x Width)
• Weight : 1.5
