FNA-20 - Eaton 20A 32V Time Delay Low Voltage Fuse Dual Element

FNA-20

FNA-20 is a 20 amp, 32 volt time delay low voltage fuse from Eaton's Bussmann FNA series designed for supplemental circuit protection.This dual-element, time-delay fuse features a 1 kA interrupt rating at 32 VAC, ferrule terminal connections, and a 2-barrel cartridge style with a diameter of 0.82 inches and length of 1.5 inches. It is CE marked and suitable for inductive load circuits and electronic applications requiring reliable time-delay protection.

• Amperage: 20 A
• Voltage Rating: 32 V AC
• Interrupt Rating: 1 kA at 32 VAC
• Fuse Type: Time Delay (Dual Element)
• Body Style: 2 Barrel Cartridge
• Connection: Ferrule Terminal Ends
• Diameter: 0.82 inches (13/32 inch)
• Length: 1.5 inches
• Certifications: CE Marked
• Series: Bussmann FNA
• Mounting Type: Cartridge Fuse Holder

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FNA-20
• Manufacturer : Eaton
• Brand : Bussmann
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FNA Series
• Type : FNA
• Voltage : 32
• Amperage : 20
• AIC rating : 1kA@32V
• Diameter : 0.82
• Class Rating : Midget
• Barrels : 2

Product Data

• UPC : 051712713672
• GTIN : 00051712713672
• Country of Origin : Mexico
• Dimensions : 0.81 in x 1.52 in x 0.4 in (Length/Depth x Height x Width)
• Weight : 0.3
• Certification : CE, CSA Class 1422-01, UL-248-12 Guide JDYX
