2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Low Voltage Fuse
Description
FNA-15
FNA-15 is an Eaton Bussmann series dual element time delay fuse rated for 15 amps and 125 volts AC.This fuse features a pin indicating design with dual elements for superior overload and cycling capabilities. It is suitable for inductive and electronic circuit protection with a high interrupt rating of 10,000 amps at 125 VAC. The fuse complies with CE marking and RoHS standards.
- Amperage Rating: 15 A
- Voltage Rating: 125 VAC
- Fuse Type: Dual Element Time Delay
- Interrupt Rating: 10 kA at 125 VAC
- Pin Indicating: Yes
- Number of Elements: Dual
- Mounting Type: Cartridge
- Material: Silver-plated pins
- Certifications: CE Marked, RoHS Compliant
- Dimensions: 13/32" x 1-1/2"
- Application: Inductive and electronic circuits
Specifications
- Part Number: FNA-15
- Manufacturer : Eaton
- Brand : Bussmann
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : FNA Series
- Type : FNA
- Voltage : 125
- Amperage : 15
- AIC rating : 10kA@125V
- Diameter : 0.82
- Class Rating : Midget
- Barrels : 2
Product Data
- UPC : 051712713665
- GTIN : 00051712713665
- Country of Origin : Mexico
- Dimensions : 0.817 in x 1.843 in x 0.817 in (Length/Depth x Height x Width)
- Weight : 0.3
- Certification : CE, CSA Class 1422-01, UL-248-12 Guide JDYX
