Product Info
- Manufacturer:Littelfuse
- Sub-Category:Low Voltage Fuse
Description
FLNR60ID
FLNR60ID is a 60A, 250V AC dual element time delay fuse with visual blown fuse indication, designed for general purpose circuit protection. This Class RK5 fuse features current limiting and advanced short-circuit and overload protection for reliable performance in a wide range of applications. The FLNR60ID fuse is constructed with a dual-element, time delay design for superior protection in service entrance switches, transformers, switchboard mains, feeders, and motor control circuits. The indicating feature provides instant visual confirmation of a blown fuse, reducing downtime and increasing safety. It is UL Listed and CSA Certified for compliance with industry standards.
- Amperage: 60A
- Voltage Rating: 250V AC, 125V DC
- Interrupting Rating: 200kA AC, 20kA DC
- Class: RK5
- Series: FLNR
- Mounting Type: Ferrule
- Physical Size: 13/16" x 3"
- Features: Dual Element, Time Delay, Current Limiting, Indicating
- Certifications: UL Listed, CSA Certified
- Standards: UL 248-12
- Applications: General Purpose, Service Entrance, Transformers, Motor Control
- Country of Origin: Mexico
Specifications
- Part Number: FLNR60ID
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Powr-Gard
- Type : FLNR
- Voltage : 250
- Amperage : 60
- AIC rating : 200kA@250V
- Connection : Ferrule Rejection
- Diameter : 0.81
- Class Rating : RK5
- Barrels : 1
- Velocity : TD - Time Delay
Product Data
- UPC : 079458023848
- GTIN : 00079458023848
- Weight : 25
