Product Info
- Manufacturer:Littelfuse
- Sub-Category:Low Voltage Fuse
Description
FLNR50ID
FLNR50ID is a Littelfuse 50 Amp, 250 Volt AC Class RK5 time delay dual element fuse with an indicator for visual blown fuse identification.This fuse provides advanced short-circuit and overload protection with a dual-element design and current limiting capability. It features a patented solid-state indicator window that turns black when blown, allowing fast and easy identification to reduce downtime. Rated for 250 VAC and 125 VDC, it has an interrupting rating of 200,000 AIC at 250 VAC and 20,000 AIC at 125 VDC. UL Listed and CSA Certified, it is suitable for general purpose circuits including motor control, switchboard mains, transformers, and service entrance switches.
- Key Specifications
- Amperage: 50 A
- Voltage Rating: 250 VAC / 125 VDC
- Class: RK5
- Time Delay Dual Element
- Indicator Fuse with Visual Blown Fuse Window
- Interrupting Rating: 200,000 AIC @ 250 VAC, 20,000 AIC @ 125 VDC
- Current Limiting
- Physical Size: 13/16" x 3"
- UL Listed (File: E81895)
- CSA Certified (File: LR29862)
- Country of Origin: Mexico
Specifications
- Part Number: FLNR50ID
- Manufacturer : Littelfuse
- Brand : Littelfuse
- Category : Fuse
- Item Subcategory : Low Voltage Fuse
- Family : Powr-Gard
- Type : FLNR
- Voltage : 250
- Amperage : 50
- AIC rating : 200kA@250V
- Connection : Ferrule Rejection
- Diameter : 0.81
- Class Rating : RK5
- Barrels : 1
- Velocity : TD - Time Delay
Product Data
- UPC : 079458023831
- GTIN : 00079458023831
- Weight : 5
