FLNR010 - Littelfuse 10A 250VAC/125VDC Class RK5 Time Delay Fuse, 200/300kA AC 20kA DC Interrupt, Cartridge Body

FLNR010

FLNR010 is a Littelfuse POWR-GARD FLNR series dual-element, time delay fuse designed for general purpose circuit protection in industrial and commercial applications. This fuse provides reliable overload and short-circuit protection for motors and other equipment requiring a slow-blow response. The FLNR010 features a cartridge body with clip terminals and is constructed for use in 250 VAC or 125 VDC circuits. Its dual-element design ensures advanced protection for circuits susceptible to inrush currents, making it suitable for distribution panelboards, industrial control panels, and service entrance switches.

• Amperage Rating: 10 A
• Voltage Rating: 250 VAC / 125 VDC
• Interrupt Rating: 200/300 kA RMS AC, 20 kA DC
• Class: RK5
• Body Style: Cartridge
• Terminal Type: Clip
• Element: Dual
• Diameter: 9/16 Inch
• Length: 2 Inch
• Series: POWR-GARD FLNR
• Speed: Time Delay, Slow Blow
• Standards: UL 248-12, CSA LR29862

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FLNR010
• Manufacturer : Littelfuse
• Brand : Littelfuse
• Category : Fuse
• Item Subcategory : Low Voltage Fuse
• Family : FLNR Series - UL Class RK5 Dual-Element Time-Delay Fuses
• Type : FLNR Series - UL Class RK5 Dual-Element Time-Delay Fuses
• Voltage : 250
• Amperage : 10
• AIC rating : 200kA@250V
• Connection : Ferrule Rejection
• Diameter : 0.56
• Class Rating : RK5
• Barrels : 1
• Velocity : TD - Time Delay

Product Data

• UPC : 079458150650
• GTIN : 00079458150650
• Country of Origin : Mexico
• Dimensions : x 2 in x
• Weight : 21.79
• Certification : CE, UL 248-12 Class RK5, CSA Certification, QPL-W-F-1814
