FH36025 - Square D 25 Amp 3 Pole 600VAC I-Line Thermal Magnetic Circuit Breaker 25kAIC@480V

FH36025

FH36025 is a Square D 3 pole, 25 amp thermal magnetic molded case circuit breaker designed for 600VAC applications with I-Line style plug-in mounting.This circuit breaker features a 25kA interrupting rating at 480V, supports 250VDC, and includes long time and instantaneous trip functions. It is UL, CSA, NOM, IEC, CCC, and CE certified, suitable for use in I-Line panelboards with line and load lug terminal connections. Rated for operation at 40°C, it accepts wire sizes from 14 AWG copper to 4 AWG copper.

Key Specifications
• Amperage: 25 Amps
• Voltage: 600VAC, 250VDC
• Poles: 3
• Mounting Type: I-Line Style Plug-In
• Interrupting Rating: 25kAIC @ 480V
• Series/Frame: FH
• Trip Unit: Thermal Magnetic with Long Time and Instantaneous Trip
• Certifications: UL, CSA, NOM, IEC, CCC, CE
• Terminal Connection: Line and Load Lug
• Temperature Rating: 40°C
• Max Wire Size: 4 AWG CU
• Min Wire Size: 14 AWG CU, 12 AWG AL

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FH36025
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FH
• Voltage : 600
• Amperage : 25
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 785901342588
• GTIN : 00785901342588
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 6
• Certification : UL, CSA, NOM, IEC, CCC, CE
