Product Info
- Manufacturer:Eaton
- Sub-Category:Disconnect
Description
FDPW368T
FDPW368T is a three-pole fusible panelboard switch designed for reliable branch circuit protection in commercial and industrial applications. This Eaton FDPW series switch features a 1200A current rating, 600VAC voltage rating, and a robust 200kAIC interrupting capacity, making it suitable for demanding electrical environments. The switch is equipped for Class L fuses and supports both cable-in and cable-out configurations, with a NEMA 1 enclosure for indoor use. Its horizontal mounting design and branch switch configuration provide flexibility for panelboard installations. Key Specifications
- Part Number: FDPW368T
- Manufacturer: Eaton
- Series/Frame: FDPW
- Amperage Rating: 1200A
- Voltage Rating: 600VAC
- Number of Poles: 3
- Interrupt Rating: 200kAIC
- Mounting Type: Horizontal, Branch
- Fuse Class: Class L
- Enclosure Type: NEMA 1
- Wire Size: (4) 250-750 kcmil or (8) #3/0 AWG-250 kcmil
- Product Weight: 35 lb
Specifications
- Part Number: FDPW368T
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Switch
- Item Subcategory : Disconnect
- Family : FDPW
- Type : FDPW
- Voltage : 600VAC
- Amperage : 1200
- Poles : 3
- AIC rating : 200kAIC
- Connection : Top Feed Main
- Nema Rating : 16X
Product Data
- UPC : 078667991319
- GTIN : 00786679913192
- Dimensions : 27 in x 11 in x 24 in (Length/Depth x Height x Width)
- Weight : 75
