FDB3150L - Cutler Hammer 150A 600V 3 Pole F-Frame Molded Case Circuit Breaker, Series C, Thermal Magnetic, 14kAIC, Panel Mount

FDB3150L

FDB3150L is a Cutler Hammer molded case circuit breaker designed for reliable protection in industrial power distribution applications.

This three-pole, 150 ampere breaker features a thermal magnetic trip unit, F-frame construction, and is rated for 600VAC/250VDC with a 14kA interrupting capacity at 480VAC. It is suitable for panelboard, switchboard, motor control center, and busway installations, offering both long-time and instantaneous overcurrent protection. The breaker is panel mount, feed-thru style, with standard pressure line and load terminals, and is backed by major certifications.

Key Specifications
• Amperage: 150A
• Voltage: 600VAC, 250VDC
• Poles: 3
• Mounting Type: Panel mount, feed-thru
• Interrupt Rating: 14kAIC at 480VAC, 18kAIC at 240VAC
• Series/Frame: Series C, F-frame
• Trip Unit: Thermal magnetic, fixed, non-interchangeable
• Certifications: UL Listed, CSA Certified, CE
• Terminals: Standard pressure line and load
• Dimensions: 6" H x 4.13" W x 3.38" D
• Application: Industrial, panelboard, switchboard, motor control center, busway
• Warranty: 1 year from installation or 18 months from shipment

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDB3150L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDB
• Voltage : 600
• Amperage : 150
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679306086
• GTIN : 00786679306086
• Country of Origin : Dominican Republic
• Dimensions : 7.4 in x 4.9 in x 5 in (Length/Depth x Height x Width)
• Weight : 4.35
• Certification : UL Listed
