FDB3125L - Cutler Hammer 125A 600VAC 3-Pole Molded Case Circuit Breaker FDB Frame Thermal Magnetic Trip

FDB3125L

FDB3125L is a Cutler Hammer molded case circuit breaker designed for industrial power distribution applications.This 3-pole breaker features a 125 ampere rating at 40°C, supports up to 600 VAC and 250 VDC, and includes a fixed thermal magnetic non-interchangeable trip unit. It is part of the Series C NEMA F-frame with panel mounting and bolt-on connection. Interrupting ratings are 18 kA at 240 VAC, 14 kA at 480 VAC and 600 VAC, and 10 kA at 250 VDC, suitable for high fault current protection. Line and load end terminals are standard.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 125 A
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 3
• Frame Type: F (Series C)
• Trip Unit: Fixed Thermal Magnetic
• Interrupting Capacity: 18 kA @ 240 VAC, 14 kA @ 480 VAC & 600 VAC, 10 kA @ 250 VDC
• Mounting Type: Panel Mount
• Connection: Bolt On
• Standard Lug Type: Line and Load
• Certifications: UL Listed (implied by manufacturer standard)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDB3125L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDB
• Voltage : 600
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679306055
• GTIN : 00786679306055
• Country of Origin : Dominican Republic
• Dimensions : 7.4 in x 4.9 in x 5 in (Length/Depth x Height x Width)
• Weight : 4.35
• Certification : UL Listed
