2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
FDB3040L
FDB3040L is a Cutler Hammer 40 Amp 3 Pole molded case circuit breaker designed for industrial panel mounting applications.This Eaton Cutler Hammer Series C FDB frame breaker features a thermal magnetic trip unit with fixed trip settings, rated for 600 VAC and 250 VDC operation. It has a 14kA interrupt rating at 480 VAC and 18kA at 240 VAC, suitable for robust circuit protection. The breaker is UL, CSA, and CE certified and designed for use at 40°C ambient temperature.
- Amperage: 40 A
- Voltage Rating: 600 VAC, 250 VDC
- Poles: 3
- Interrupt Rating: 14kA @ 480 VAC, 18kA @ 240 VAC
- Trip Unit: Thermal Magnetic, Fixed Trip
- Frame/Series: FDB, Series C
- Mounting Type: Panel Mount
- Certifications: UL, CSA, CE
- Operating Temperature: 40°C
- Dimensions: Approx. 4.125" W x 3.375" D x 6" H
Specifications
- Part Number: FDB3040L
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FDB
- Voltage : 600
- Amperage : 40
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679305928
- GTIN : 00786679305928
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
