Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FD4110
FD4110 is an Eaton Series C complete molded case circuit breaker designed for four-pole electrical distribution and protection in 600V systems. This F-frame breaker features fixed thermal and fixed magnetic trip protection, delivering reliable overcurrent and fault protection across all four phases with a 110-amp current rating suitable for industrial and commercial applications.Key Specifications
- Manufacturer: Eaton (Cutler-Hammer)
- Part Number: FD4110
- Series: C
- Frame Type: F-Frame
- Circuit Breaker Type: FD
- Amperage Rating: 110 Amp
- Voltage Rating: 600 VAC, 250 VDC
- Number of Poles: 4
- Trip Type: Fixed Thermal, Fixed Magnetic
- Interrupt Rating: 65 kAIC at 240 VAC, 35 kAIC at 480 VAC
- Frequency: 50/60 Hz
- Connection Type: Bolt-on Line and Load
- UL Listed 100%-Rated
Specifications
- Part Number: FD4110
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FD
- Voltage : 600
- Amperage : 110
- Phase : 3
- Poles : 4
- AIC rating : 25kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679251157
- GTIN : 00786679251157
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 5.5 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
