FD3225VW - Cutler Hammer FD Series C Molded Case Circuit Breaker 225A 3P 600VAC Bolt-On

FD3225VW

FD3225VW is a Cutler Hammer Series C molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This three-pole breaker features a 225 amp rating, 600 VAC maximum voltage, and a bolt-on mounting configuration for secure installation. The FD3225VW provides thermal magnetic protection with fixed long-time and instantaneous trip functions, suitable for panelboard, switchboard, motor control center, and busway applications. It is rated for 65kA interrupt at 240VAC and 35kA at 480VAC, ensuring robust performance under fault conditions.

• Part Number: FD3225VW
• Manufacturer: Cutler Hammer
• Series: Series C
• Frame Type: F Frame
• Poles: 3
• Amperage: 225A
• Maximum Voltage: 600 VAC / 250 VDC
• Mounting Type: Bolt-On
• Interrupt Rating: 65kA @ 240VAC, 35kA @ 480VAC
• Protection Type: Thermal Magnetic
• Standards: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: FD3225VW
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 225
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 78211697416
• GTIN : 00782116974160
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
