FD3125L - Cutler Hammer 125A 600V 3-Pole FD Frame Circuit Breaker

FD3125L

FD3125L is a Cutler Hammer 3-pole molded case circuit breaker designed for 125 ampere current at 600 volts AC.This FD frame circuit breaker features a 3-pole configuration with a 125 amp rating and a voltage rating of 600 VAC and 250 VDC. It includes a T186 trip unit and offers interrupt ratings up to 65kA at 240VAC and 35kA at 480VAC. The breaker is suitable for industrial and commercial power distribution applications requiring reliable overcurrent protection.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton Division)
• Part Number: FD3125L
• Amperage: 125A
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 3
• Frame Type: FD
• Trip Unit: T186
• Interrupt Rating: 65kA @ 240VAC, 35kA @ 480VAC
• Mounting Type: Molded Case
• Series: Series C
• Certifications: UL Listed, CSA Certified (typical for Cutler Hammer breakers)
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: FD3125L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic



Product Data

• UPC : 786679851272
• GTIN : 00786679851272
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
