Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FD3100I
FD3100I is a 100 amp, 3-pole molded case circuit breaker from Eaton, designed for industrial power distribution applications.FD3100I features a thermal magnetic trip unit with long-time and instantaneous trip functions, suitable for 600V AC and 480Y/277V three-phase four-wire systems. It belongs to Eaton's Series C, F-frame family and offers a 35kA interrupting rating at 480V. This breaker includes line and load side lug terminals and is designed for feed-thru mounting.
- Amperage: 100A
- Voltage Rating: 600V AC, 480Y/277V three-phase
- Poles: 3
- Frame Type: F-Frame, Series C
- Trip Unit: Thermal Magnetic with Long-Time and Instantaneous functions
- Interrupt Rating: 35kA at 480V
- Mounting Type: Feed-Thru
- Connection: Line and Load Side Lug Terminals
- Dimensions: Approximately 6" H x 4.13" W x 3.38" D
- Standards: Meets Eaton Cutler-Hammer specifications
Specifications
- Part Number: FD3100I
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
Product Data
- UPC : 782114738474
- GTIN : 00782115000000
- Dimensions : 3.75 in x 6 in x 2.75 in (Length/Depth x Height x Width)
- Weight : 7
- Certification : UL Listed
