FD3100 - Cutler Hammer 100A 600VAC 3 Pole Molded Case Circuit Breaker F Frame

FD3100

FD3100 is a Cutler Hammer molded case circuit breaker designed for reliable circuit protection in industrial and commercial applications.FD3100 features a 100 ampere rating, 600 VAC/250 VDC voltage rating, and 3 poles with a thermal magnetic trip unit. It is part of the Eaton Series C, F frame, type FD breakers, offering a 35 kA interrupt rating at 480 VAC and fixed thermal/magnetic trip protection.

Key Specifications
• Amperage: 100 A
• Voltage: 600 VAC / 250 VDC
• Poles: 3
• Interrupt Rating: 35 kA at 480 VAC
• Frame: F Frame
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Mounting Type: Feed-Thru
• Category: Molded Case Circuit Breaker
• Standards: Eaton Series C, Type FD
• Connection: Line and Load Side Lugs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD3100
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Load Side Lug
• Frame Size : 225A/F
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 786679305768
• GTIN : 00786679305768
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
