FD3090L - Cutler Hammer 90A 600V 3-Pole FD Frame Circuit Breaker Series C

FD3090L

FD3090L is a Cutler Hammer 3-pole molded case circuit breaker designed for 90 ampere current rating and 600 volts AC operation.This FD frame Series C circuit breaker features a T186 trip unit and is rated for 90 amps with voltage ratings of 600 Vac and 250 Vdc. It offers a standard interrupting capacity of up to 35kA at 480V and 65kA at 240V, suitable for robust power distribution and protection applications.

• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 90A
• Voltage: 600 Vac, 250 Vdc
• Poles: 3
• Frame Type: FD (Series C)
• Trip Unit: T186
• Interrupt Rating: 35kA @ 480V, 65kA @ 240V
• Mounting Type: Molded Case
• Certification: UL Listed
• Temperature Rating: 40°C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD3090L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679156506
• GTIN : 00786679156506
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.45
• Certification : UL Listed
