FD3060VW - Cutler Hammer 60A 600VAC 3-Pole Molded Case Circuit Breaker F-Frame Fixed Thermal Magnetic Trip

FD3060VW

FD3060VW is a Cutler Hammer molded case circuit breaker designed for reliable circuit protection with a 60 amp rating and 600 VAC voltage capacity.This Eaton Series C, F-frame breaker features a fixed thermal and fixed magnetic trip unit, providing thermal magnetic protection for three-pole applications. It supports 600 VAC and 250 VDC operation with a high interrupt rating of 65 kA at 240 VAC and 35 kA at 480 VAC. The breaker is panel mountable and includes line and load side lug terminals for feed-thru connections. UL listed for safety and compliance.

Key Specifications
• Amperage: 60 A
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 3
• Frame Type: F-Frame
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Interrupt Rating: 65 kA at 240 VAC, 35 kA at 480 VAC
• Mounting Type: Panel Mount
• Series: Eaton Series C
• Phase: 3
• Connection: Feed-Thru with line & load lug terminals
• Certifications: UL Listed
• Operating Frequency: 50/60 Hz

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD3060VW
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer

Product Data

• UPC : 78667907203
• GTIN : 00786679072035
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
