FD3060 - Eaton Cutler Hammer 60A 600V 3 Pole FD Frame Circuit Breaker Thermal Magnetic

FD3060

FD3060 is a 3-pole, 60 ampere, 600 VAC molded case circuit breaker from Eaton Cutler Hammer's Series C FD frame. It features a thermal magnetic trip unit for reliable circuit protection.

This Eaton FD3060 breaker is designed for panel mount applications with a fixed thermal and magnetic trip type. It has a 35kA interrupt rating at 480 VAC and 65kA at 240 VAC, suitable for industrial use. The breaker supports 600 VAC and 250 VDC ratings, with line and load side lug terminals and complies with UL and CSA certifications. Its dimensions are approximately 6" H x 4.13" W x 3.38" D, weighing 4.5 lbs.

Key Specifications
• Amperage: 60 A
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 3
• Frame Type: FD (F Frame)
• Trip Unit: Fixed Thermal Magnetic
• Interrupt Rating: 35 kA at 480 VAC, 65 kA at 240 VAC
• Mounting Type: Panel mount, bolt-on
• Approvals: UL Listed, CSA Certified
• Dimensions: 6" H x 4.13" W x 3.38" D
• Weight: 4.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD3060
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Load Side Lug
• Frame Size : 225A/F
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 786679305713
• GTIN : 00786679305713
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
