Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
FD1060
FD1060 is a 60 amp, 277 volt, 1-pole molded case circuit breaker manufactured by Westinghouse designed for bolt-on mounting.This FD series breaker features a 35kA interrupting rating at 277 volts AC, suitable for protecting low voltage distribution systems. It uses a bolt-on mounting type and is part of the Westinghouse F-frame series, providing reliable thermal magnetic trip protection. The breaker is UL listed and designed for industrial and commercial electrical applications.
- Key Specifications
- Amperage: 60A
- Voltage: 277V AC
- Poles: 1
- Mounting Type: Bolt-On
- Interrupting Rating: 35kA at 277V
- Series/Frame: F-Frame (FD Series)
- Trip Unit: Thermal Magnetic
- Certifications: UL Listed
Specifications
- Part Number: FD1060
- Manufacturer : Westinghouse
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FD
- Voltage : 277
- Amperage : 60
- Phase : 1
- Poles : 1
- AIC rating : 35kA@277V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679312162
- GTIN : 00786679312162
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
