Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
FCL24100
FCL24100 is a 2-pole, 100A, 480V molded case circuit breaker designed for reliable protection in commercial and industrial applications. This Square D FCL series breaker features a 65kA interrupt rating and is suitable for use in panelboards and switchgear. The FCL24100 is a thermal-magnetic molded case circuit breaker with a robust frame and field-reversible lugs for flexible installation. It is UL listed, CSA certified, and HACR rated for use in a variety of environments. The breaker is designed for easy DIN rail mounting and includes a common trip mechanism for enhanced safety.
- Part Number: FCL24100
- Manufacturer: Square D
- Series/Frame: FCL
- Amperage: 100A
- Voltage: 480V AC
- Poles: 2
- Interrupt Rating: 65kAIC @ 480V
- Mounting Type: DIN Rail
- Trip Unit: Thermal-Magnetic
- Certifications: UL Listed, CSA Certified, HACR Rated
- Field Reversible Lugs: Yes
- Common Trip: Yes
Specifications
- Part Number: FCL24100
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FCL Series
- Type : FCL
- Voltage : 480
- Amperage : 100
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 722511266521
- Weight : 3
