Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
FC34015
FC34015 is a 3 pole, 15 amp, 480 volt I-Line style plug-in circuit breaker from Square D's FC series.This thermal magnetic molded case circuit breaker features a 65kA interrupting rating at 480VAC, providing reliable protection with long-time and instantaneous trip functions. It is UL and CSA certified and designed for three-phase industrial applications with plug-on mounting.
- Key Specifications
- Manufacturer: Square D
- Part Number: FC34015
- Amperage: 15 Amps
- Voltage Rating: 480 VAC
- Poles: 3
- Interrupting Rating: 65kA at 480V
- Frame/Series: FC
- Mounting Type: I-Line Style Plug-In
- Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
- Certifications: UL, CSA
- Phase: 3
Specifications
- Part Number: FC34015
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : I-Line
- Type : FC
- Voltage : 480
- Amperage : 15
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : I-Line Style Plug-In
- Functions : LI - Long-Time and Instantaneous Trip
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 785901031550
- GTIN : 00785901031550
- Weight : 6
