Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
FBV36TE045R2
FBV36TE045R2 is a General Electric Record Plus molded case circuit breaker designed for reliable protection in industrial and commercial power distribution systems. This 3-pole breaker features a 45A current rating, 600VAC maximum voltage, and a bolt-on mounting configuration for secure installation. It utilizes a fixed thermal magnetic trip unit for consistent performance and safety. The breaker is rated for 35 kA at 480 VAC and 65 kA at 240 VAC interrupt capacity, making it suitable for a wide range of applications. The Record Plus series is known for its robust construction and advanced safety features. Key Specifications
- Part Number: FBV36TE045R2
- Manufacturer: General Electric
- Series: Record Plus
- Amperage: 45A
- Voltage: 600VAC
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 35 kA at 480 VAC / 65 kA at 240 VAC
- Trip Unit: Fixed Thermal Magnetic
- Frame: FBV
- Standards: UL 489 Listed
- Application: Industrial and Commercial Power Distribution
Specifications
- Part Number: FBV36TE045R2
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Record Plus
- Type : FBV
- Voltage : 600
- Amperage : 45
- Phase : 3
- Poles : 3
- AIC rating : 150kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164336283
- GTIN : 00783164336283
- Weight : 4
