Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
FBV26TE090RV
FBV26TE090RV is a General Electric 90 Amp, 600 Volt, 2 Pole molded case circuit breaker designed for bolt-on mounting.This thermal magnetic circuit breaker features a robust FB frame type, providing reliable overcurrent protection in industrial and commercial electrical systems. It supports 2 poles and is rated for 600 VAC operation with a 90 Amp current capacity. The breaker is designed for bolt-on installation, ensuring secure and stable mounting. It meets industry standards for safety and performance.
- Amperage: 90 Amps
- Voltage: 600 Volts AC
- Number of Poles: 2
- Mounting Type: Bolt-On
- Frame Type: FB
- Trip Unit: Thermal Magnetic
- Interrupt Rating: 150kA at 480V (typical for FB frame)
- Category: Molded Case Circuit Breaker
- Manufacturer: General Electric
- Application: Industrial and Commercial Electrical Protection
Specifications
- Part Number: FBV26TE090RV
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Record Plus
- Type : FBV
- Voltage : 600
- Amperage : 90
- Phase : 1
- Poles : 2
- AIC rating : 150kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous Trip
- Protection : Thermal Magnetic
Product Data
- UPC : 783164394580
- Weight : 3
