Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
FBN36TE050R2
FBN36TE050R2 is a 3 pole, 50 amp, 600V molded case circuit breaker from General Electric, designed for reliable thermal magnetic protection in commercial and industrial applications. This General Electric Record Plus series breaker features a bolt-on mounting design, high interrupting capacity, and is suitable for use in a wide range of electrical distribution panels. The breaker is built for durability and offers long-term performance with easy installation and maintenance.
- Part Number: FBN36TE050R2
- Manufacturer: General Electric
- Series/Frame: Record Plus, FC100
- Amperage: 50A
- Voltage: 600V AC, 347V AC
- Poles: 3 Pole
- Mounting Type: Bolt-On
- Interrupt Rating: 65kA @ 480V, 25kA @ 600V
- Trip Unit: Thermal Magnetic (LI)
- Certifications: UL Listed, CSA Certified
- Dimensions: 4.11" W x 3.28" D x 6.45" H
- Weight: 33 lbs
Specifications
- Part Number: FBN36TE050R2
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Record Plus
- Type : FBN
- Voltage : 600
- Amperage : 50
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164336559
- Dimensions : Depth / Length 8.500 in X Height 5.000 in X Width 4.500 in
- Weight : 4
