Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
FBN26TE070RV
FBN26TE070RV is a General Electric Record Plus 2 pole, 70 amp, 600V bolt-on molded case circuit breaker designed for high interrupting capacity applications. This breaker features a thermal magnetic trip unit with long time and instantaneous protection, suitable for use in commercial and industrial power distribution systems. The FBN26TE070RV is part of the FB 100 frame series and is rated for 65kAIC at 480VAC, with a 240VAC interrupting rating of 150kAIC. It is UL listed, HACR marked, and suitable for reverse feed applications. The breaker includes load side lug terminals and is designed for bolt-on mounting in compatible panels.
- Part Number: FBN26TE070RV
- Manufacturer: General Electric
- Series: Record Plus
- Frame Type: FB 100
- Amperage: 70A
- Voltage: 600VAC
- Poles: 2
- Mounting Type: Bolt-On
- Interrupting Rating: 65kAIC @ 480VAC
- Interrupting Rating: 150kAIC @ 240VAC
- Trip Unit: Thermal Magnetic, LI (Long Time and Instantaneous)
- Terminals: Load Side Lug
- Certifications: UL Listed, HACR Marked
- Suitable for Reverse Feed: Yes
Specifications
- Part Number: FBN26TE070RV
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Record Plus
- Type : FBN
- Voltage : 600
- Amperage : 70
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164394696
- Dimensions : Depth / Length 8.500 in X Height 4.750 in X Width 3.250 in
- Weight : 3
- Certification : UL
