Product Info
- Manufacturer:General Electric
- Sub-Category:Molded Case
Description
FBN16TE020RV
FBN16TE020RV is a 1 pole, 20 amp, 600 volt thermal magnetic molded case circuit breaker from General Electric's Record Plus series.This circuit breaker features a fixed thermal and magnetic trip unit with a high interrupting rating of 65kA at 480V, suitable for industrial and commercial applications. It is UL and CSA certified, designed for bolt-on mounting, and replaces older TED series models. The breaker offers reliable protection with a compact size and robust construction.
- Amperage: 20 Amps
- Voltage Rating: 600 Volts
- Number of Poles: 1 Pole
- Interrupting Rating: 65kA at 480V
- Trip Unit: Thermal Magnetic
- Mounting Type: Bolt-On
- Series/Frame: Record Plus
- Certifications: UL Listed, CSA Certified
- Dimensions: Approx. 4.11" W x 3.28" D x 6.45" H
- Weight: Approx. 2.615 lbs
Specifications
- Part Number: FBN16TE020RV
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Record Plus
- Type : FBN
- Voltage : 600
- Amperage : 20
- Phase : 1
- Poles : 1
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 783164394092
- GTIN : 00783164394092
- Dimensions : Depth / Length 8.500 in X Height 4.250 in X Width 3.250 in
- Weight : 1
- Certification : UL
- Wire Size : 14-10 AWG (Cu/Al)
