Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FAZ-D7/2
FAZ-D7/2-NA is an Eaton 7 ampere, 2-pole miniature circuit breaker designed for branch and feeder protection with a D curve thermal magnetic trip.
This current-limiting breaker supports 480Y/277 VAC and 96 VDC voltage ratings, features a 10kA interrupting rating at 480Y/277 VAC, and mounts on a 35mm DIN rail. It is UL 489 listed, CSA certified, RoHS compliant, and suitable for high inrush current applications such as motors and transformers.
- Key Specifications
- Amperage Rating: 7 A
- Voltage Rating: 480Y/277 VAC, 96 VDC
- Number of Poles: 2
- Trip Curve: D curve
- Trip Type: Thermal magnetic
- Interrupting Rating: 10 kA @ 480Y/277 VAC
- Mounting Type: 35mm DIN rail
- UL Listed (UL 489)
- CSA Certified (C22.2 No. 235)
- RoHS Compliant
- Current Limiting Feature
- HACR Rated and Reverse Feed Capable
- Part Number: FAZ-D7/2
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAZ Series
- Type : FAZ
- Voltage : 480
- Amperage : 7
- Phase : 1
- Poles : 2
- AIC rating : 10kA@277/480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Protection : Thermal Magnetic
- UPC : 01508163992
- GTIN : 04015081639922
- Dimensions : 1.5 in x 1.5 in x 1.5 in (Length/Depth x Height x Width)
- Weight : 0.5
