FAZ-D7/2-NA - Eaton 7A 2-Pole Miniature Circuit Breaker 480Y/277 VAC 10kA DIN Rail Mount

FAZ-D7/2-NA

FAZ-D7/2-NA is a 7 amp, 2-pole Eaton miniature circuit breaker designed for branch and feeder circuit protection.This thermal magnetic breaker features a D curve trip characteristic, 10kA interrupting rating at 480Y/277 VAC, and mounts on a 35mm DIN rail.

Key Specifications
• Amperage: 7A
• Voltage Rating: 480Y/277 VAC, 96 VDC
• Number of Poles: 2
• Trip Curve: D curve
• Trip Type: Thermal magnetic
• Interrupting Rating: 10kA @ 480Y/277 VAC
• Mounting Type: 35mm DIN rail
• UL Listed (UL 489), CSA Certified
• Current Limiting: Yes
• HACR Rated: Yes
• Reverse Feed Capable: Yes
• RoHS Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-D7/2-NA
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-NA
• Voltage : 480
• Amperage : 7
• Phase : 1
• Poles : 2
• AIC rating : 10kA@277/480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous Trip
• Terminal Connection : Screw Clamp
• Frame Size : 40A/FAZ
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 18 AWG Max. Wire Size 6 AWG
• Protection : Thermal Magnetic

Product Data

• UPC : 01508102061
• GTIN : 04015081020614
• Country of Origin : Spain
• Dimensions : 1.5 in x 4.25 in x 3 in (Length/Depth x Height x Width)
• Weight : 0.5
• Standards : CSA Certified, IEC 60947-2, UL 489 Listed
• Certification : CSA Certified, IEC 60947-2, UL 489 Listed
• Wire Size : AWG 18 to AWG 6, AWG 18 to AWG 10
