FAZ-D7/1-SP - Eaton Cutler Hammer 7A 277V 1-Pole Thermal Magnetic Circuit Breaker UL 1077

FAZ-D7/1-SP

FAZ-D7/1-SP is a 1-pole thermal magnetic circuit breaker rated for 7 amps and 277 volts, designed as a supplementary protector by Eaton, Cutler Hammer.This Eaton FAZ-D7/1-SP circuit breaker features a 10kA interrupting rating at 277V, UL 1077 and CSA certifications, and is suitable for high inrush current applications such as motors and transformers. It has standard terminals and a D curve trip characteristic (10-20X/n), making it ideal for industrial miniature circuit protection on DIN rail mounts.

• Amperage Rating: 7 Amps
• Voltage Rating: 277 VAC / 48 VDC
• Number of Poles: 1 (Single-pole)
• Interrupting Rating: 10 kA @ 277 V
• Trip Type: Thermal Magnetic, D Curve (10-20X/n)
• Mounting Type: DIN Rail
• Terminals: Standard
• Certifications: UL 1077, CSA Std. C22.2 No.235, IEC 60947-2
• Frame/Series: FAZ Supplementary Protector
• High inrush current tolerance for motors and transformers
• Compact size: approx. 1 inch cube

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-D7/1-SP
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ
• Voltage : 27
• Amperage : 7
• Phase : 1
• Poles : 1
• AIC rating : 10kA@277V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Protection : Thermal Magnetic

Product Data

• UPC : 015081639780
• Country of Origin : Germany
• Dimensions : 1 in x 1 in x 1 in (Length/Depth x Height x Width)
• Weight : 0.5
