FAZ-D6/2-RT - Eaton 6 Amp 2 Pole 277/480 VAC Miniature Circuit Breaker D-Curve Thermal Magnetic Trip

FAZ-D6/2-RT

FAZ-D6/2-RT is a 6 amp, 2 pole miniature circuit breaker from Eaton designed for industrial and commercial electrical protection.This Eaton FAZ-D6/2-RT circuit breaker features a current limiting design with a 10 to 20X D-curve thermal magnetic trip characteristic, suitable for high inrush current applications. It is rated for 277/480 VAC operation with an interrupt rating of 10 to 15 kAIC. The breaker mounts on standard 35 mm DIN rail and includes ring tongue terminals for secure wiring. It complies with UL 489 standards and is part of Eaton's Moeller series FAZ family.

Key Specifications
• Amperage: 6 A
• Voltage Rating: 277/480 VAC
• Number of Poles: 2
• Interrupt Rating: 10 to 15 kAIC
• Trip Unit: Thermal Magnetic, D-Curve (10 to 20X In)
• Mounting Type: 35 mm DIN rail
• Terminal Type: Ring tongue terminals
• Series/Frame: Eaton FAZ Moeller series
• Frequency: 50/60 Hz
• Certifications: UL 489, CSA
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: FAZ-D6/2-RT
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-RT
• Voltage : 480
• Amperage : 6
• Phase : 1
• Poles : 2
• AIC rating : 10kA@277/480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic



Product Data

• UPC : 401508102100
• GTIN : 04015081021000
• Country of Origin : Germany
• Dimensions : 3 in x 3 in x 3 in (Length/Depth x Height x Width)
• Weight : 1
