FAZ-D3/2 - Eaton 3A 2-Pole Industrial Miniature Circuit Breaker D Curve 277/480V UL 489 CSA Certified

FAZ-D3/2

FAZ-D3/2 is an Eaton industrial miniature circuit breaker designed as a supplementary protector with a 3 ampere rating and two poles.This Eaton FAZ-D3/2 circuit breaker features a D curve trip characteristic suitable for high inrush current applications such as motors and transformers. It is rated for 277/480 volts AC with a 15 kA interrupting capacity and complies with UL 489, UL 1077, CSA C22.2 No. 235, and IEC 60947-2 standards. The breaker uses standard screw terminals and is designed for DIN rail mounting.

• Amperage: 3 A
• Voltage Rating: 277/480 V AC
• Number of Poles: 2
• Trip Curve: D Curve (10-20x In)
• Interrupting Rating: 15 kAIC
• Mounting Type: DIN Rail
• Terminal Type: Standard Screw Terminals
• Certifications: UL 489, UL 1077, CSA C22.2 No. 235, IEC 60947-2
• Weight: 0.5 lb
• Dimensions (HxWxD): approx. 1.5 x 2 x 1.5 inches
• Warranty: 1 year

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-D3/2
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ
• Voltage : 2
• Amperage : 3
• Phase : 1
• Poles : 2
• AIC rating : 10kA@277/480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• MCM Size : Min. Wire Size 18 AWG Max. Wire Size 4 AWG
• Protection : Thermal Magnetic

Product Data

• UPC : 015082787732
• Country of Origin : Romania
• Dimensions : 1.5 in x 1.5 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.5
• Standards : CSA C22.2 No. 235, IEC 60947-2, UL 1077
• Certification : CSA C22.2 No. 235, IEC 60947-2, UL 1077
