FAZ-D20/2 - Eaton 20A 2-Pole 277/480VAC 96VDC Thermal Magnetic DIN Rail Miniature Circuit Breaker, D Curve, 5kA Interrupt Rating, UL 489

FAZ-D20/2

FAZ-D20/2 is a two-pole, thermal magnetic miniature circuit breaker from Eaton, designed for reliable branch circuit protection in industrial applications.

This Eaton FAZ-D20/2 offers current-limiting performance, a D curve trip characteristic for high inrush loads, and is suitable for 277/480VAC or 96VDC systems. It mounts on a standard 35mm DIN rail and is certified to UL 489 standards for branch circuit protection.

Key Specifications
• Amperage: 20A
• Voltage: 277/480VAC, 96VDC
• Poles: 2
• Mounting Type: 35mm DIN rail
• Interrupt Rating: 5kA @ 480Y/277VAC (some sources note 14kA or 15kA, verify for your application)
• Series/Frame: FAZ
• Trip Unit: Thermal magnetic, D curve (10–20x In)
• Certifications: UL 489 listed
• Current Limiting: Yes
• Frequency: 50–60 Hz
• Country of Origin: Spain
• Weight: 0.268 kg

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-D20/2
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ
• Voltage : 15
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 10kA@277/480V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• MCM Size : Min. Wire Size 18 AWG Max. Wire Size 4 AWG
• Protection : Thermal Magnetic

Product Data

• UPC : 01508278784
• GTIN : 04015082787844
• Country of Origin : Romania
• Dimensions : 1.5 in x 1.5 in x 2 in (Length/Depth x Height x Width)
• Weight : 0.5 lb
• Standards : CSA C22.2 No. 235, IEC 60947-2, UL 1077
• Certification : CSA C22.2 No. 235, IEC 60947-2, UL 1077
