FAZ-D15/2-RT - Eaton 15A 2-Pole Miniature Circuit Breaker D Curve 15kAIC UL 1077 Industrial Supplementary Protector

FAZ-D15/2-RT

FAZ-D15/2-RT is a 15 amp, 2-pole miniature circuit breaker with D curve tripping characteristic designed for industrial and advanced commercial applications.This Eaton FAZ series supplementary protector features a 15 kA interrupting rating at 480Y/277 VAC, suitable for high inrush current loads such as motors and transformers. It complies with UL 1077, IEC 60947-2, and CSA C22.2 No. 235 standards. The breaker mounts on a 35mm DIN rail and has standard terminals for easy installation.

• Amperage Rating: 15 A
• Number of Poles: 2
• Tripping Characteristic: D Curve (10-20X /n)
• Interrupting Rating: 15 kAIC at 480Y/277 VAC
• Rated Operational Voltage: 277/480Y VAC, 60 VDC
• Standards: UL 1077, IEC 60947-2, CSA C22.2 No. 235
• Mounting Type: 35mm DIN Rail
• Terminal Type: Standard
• Product Dimensions: Approx. 1.5 x 1.5 x 2 inches
• Application: Industrial and advanced commercial switchgear

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-D15/2-RT
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-RT
• Voltage : 480
• Amperage : 15
• Phase : 1
• Poles : 2
• AIC rating : 14kA@277/480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 015081021059
• Country of Origin : Germany
• Dimensions : 3 in x 3 in x 3 in (Length/Depth x Height x Width)
• Weight : 1
