FAZ-C6/2-NA - Eaton 6 Amp 2 Pole Thermal Magnetic Circuit Breaker 277/480VAC 10-15kA Interrupt DIN Rail Mount

FAZ-C6/2

FAZ-C6/2-NA is a 2 pole, 6 amp thermal magnetic circuit breaker from Eaton designed for industrial and commercial applications.FAZ-C6/2-NA features a C curve trip characteristic suitable for medium inrush currents, with a voltage rating of 277/480VAC and interrupting ratings up to 15 kAIC. It mounts easily on a standard 35 mm DIN rail and complies with UL 489, UL 1077, CSA, IEC, and CE certifications. This breaker includes long time and instantaneous trip functions and supports wire sizes from 18 to 6 AWG.

Key Specifications
• Amperage: 6 A
• Voltage Rating: 277/480 VAC, 48/96 VDC
• Poles: 2
• Mounting Type: DIN Rail
• Interrupting Rating: 10 to 15 kAIC
• Trip Unit: Thermal Magnetic, C Curve
• Standards: UL 489, UL 1077, CSA C22.2, IEC 60947-2, CE, VDE
• Wire Gauge Range: 18 to 6 AWG
• Terminal Connection: Line and Load
• Operating Temperature: -4 to 140°F
• Actuator Type: Toggle

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-C6/2
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ
• Voltage : 1
• Amperage : 6
• Phase : 1
• Poles : 2
• AIC rating : 10kA@277/480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• MCM Size : Min. Wire Size 18 AWG Max. Wire Size 4 AWG
• Protection : Thermal Magnetic

Product Data

• UPC : 015082787541
• Country of Origin : Romania
• Dimensions : 1.38 in x 1.38 in x 1.5 in (Length/Depth x Height x Width)
• Weight : 0.53
• Standards : CSA C22.2 No. 235, IEC 60947-2, UL 1077
• Certification : CSA C22.2 No. 235, IEC 60947-2, UL 1077
