Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FAZ-C32/4
FAZ-C32/4 is a 32 amp, 4-pole Eaton miniature circuit breaker designed for industrial supplementary protection under UL 489 standards.This Eaton FAZ branch protector features a C curve trip unit suitable for medium inrush currents, rated for 277/480 volts AC, with a 10 kA interrupt rating and 5-10X/n trip type. It includes screw terminals and operates at 50-60 Hz frequency, providing reliable circuit protection in industrial applications.
- Amperage Rating: 32 A
- Voltage Rating: 277/480 V AC
- Number of Poles: Four-pole
- Interrupt Rating: 10 kAIC
- Trip Curve: C Curve
- Trip Type: 5-10X /n
- Frequency: 50-60 Hz
- Terminals: Screw
- Mounting Type: DIN rail
- Certifications: UL 489
- Application: Suitable for medium inrush current protection
- Weight: Approximately 1.17 lb
Specifications
- Part Number: FAZ-C32/4
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAZ Series
- Type : FAZ
- Voltage : 480
- Amperage : 32
- Phase : 3
- Poles : 4
- AIC rating : 10kA@277/480V
- Connection : Feed-Thru
- Functions : LI - Long Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 01508279064
- GTIN : 04015082790646
- Dimensions : 2.76 in x 2.76 in x 2.9 in (Length/Depth x Height x Width)
- Weight : 0.5
