Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FAZ-C25/1N
FAZ-C25/1N is a single pole miniature circuit breaker from Eaton, designed for reliable protection in electrical distribution systems. This breaker features a 25A current rating and is rated for 240VAC operation, making it suitable for a wide range of commercial and industrial applications. The C curve trip characteristic provides protection against moderate overloads and short circuits, ensuring optimal safety for connected equipment. Engineered for DIN rail mounting, the FAZ-C25/1N offers easy installation and space-saving design. It is built to meet rigorous safety standards and delivers dependable performance in demanding environments. The breaker is current-limiting and features a thermal magnetic trip unit for precise protection.
- 25A Amperage Rating
- 240VAC Voltage Rating
- Single Pole Configuration
- DIN Rail Mounting
- C Curve Trip Characteristic
- Thermal Magnetic Trip Unit
- 15 kA Interrupt Rating (IEC 60947-2)
- Current Limiting Design
- UL 489 Listed
- CSA Certified
- IEC 60947-2 Compliant
- UL File Number E235139
Specifications
- Part Number: FAZ-C25/1N
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAZ Series
- Type : FAZ
- Voltage : 2
- Amperage : 25
- Phase : 1
- Poles : 1
- AIC rating : 10kA@277/480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 015082786766
- Country of Origin : Germany
- Dimensions : 1.38 in x 1.38 in x 3 in (Length/Depth x Height x Width)
- Weight : 0.45
