FAZ-C20/2-NA - Eaton 20A 2-Pole 277/480V C Curve Miniature Circuit Breaker, 14kA Interrupt Rating, UL 489, DIN Rail Mount

FAZ-C20/2-NA

FAZ-C20/2-NA is a two-pole, 20A miniature circuit breaker from Eaton, designed for branch circuit protection in industrial and commercial applications.

This Eaton FAZ series circuit breaker features a C curve trip characteristic, making it suitable for circuits with medium inrush currents such as small transformers and pilot devices. It is UL 489 listed for use as a supplementary protector, offers a high interrupting capacity, and is designed for easy DIN rail mounting.

Key Specifications
• Amperage: 20A
• Voltage: 277/480V AC, 96V DC
• Poles: 2
• Mounting Type: 35mm DIN rail
• Interrupt Rating: 14kA at 277/480V AC, 10kA at lower voltages
• Series/Frame: FAZ-NA
• Trip Unit: Thermal-magnetic, C curve (5–10x In)
• Frequency: 50/60 Hz
• Terminals: Screw
• Certifications: UL 489, CSA C22.2 No. 235
• Application: Protects circuits with medium inrush currents
• Product Dimensions: 1.4" D x 4.13" H x 2.97" W

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-C20/2-NA
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-NA
• Voltage : 480
• Amperage : 20
• Phase : 1
• Poles : 2
• AIC rating : 14kA@277/480V
• Connection : Din Rail
• Functions : LI - Long Time and Instantaneous
• Terminal Connection : Screw Clamp
• Frame Size : 40A/FAZ
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 18 AWG Max. Wire Size 6 AWG
• Protection : Thermal Magnetic

Product Data

• UPC : 78668900516
• GTIN : 00786689005160
• Country of Origin : Spain
• Dimensions : 1.4 in x 4.13 in x 2.97 in (Length/Depth x Height x Width)
• Weight : 1
• Standards : CSA Certified, IEC 60947-2, UL 489 Listed
• Certification : CSA Certified, IEC 60947-2, UL 489 Listed
• Wire Size : 18 to 6 AWG, 18 to 10 AWG
