Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FAZ-C20/1-NA-DC-SP
FAZ-C20/1-NA-DC-SP is an Eaton industrial miniature circuit breaker designed for reliable supplementary protection in DC applications.
This single-pole, current-limiting breaker features a C curve trip characteristic for moderate inrush loads, a 20A amperage rating, and a maximum voltage rating of 125VDC per pole. It mounts on standard 35mm DIN rail for easy panel integration and offers a high interrupting rating of 10kA. The FAZ-NA series is UL 489 listed, ensuring compliance with North American safety standards for branch circuit protection.
Key Specifications
- Part Number: FAZ-C20/1-NA-DC-SP
- Manufacturer: Eaton
- Amperage: 20A
- Voltage: 125VDC (per pole)
- Poles: 1
- Mounting Type: 35mm DIN rail
- Interrupt Rating: 10kA
- Series/Frame: FAZ-NA
- Trip Unit: Thermal magnetic, C curve (5–10x In)
- Certifications: UL 489
- Frequency: 50/60 Hz
- Terminal Type: Screw
- Application: Supplementary protector for DC branch circuits
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: FAZ-C20/1-NA-DC-SP
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Voltage : 125
Product Data
- UPC : 4015081636563
- Country of Origin : Spain
- Dimensions : 0.7 in x 4.13 in x 2.97 in (Length/Depth x Height x Width)
- Weight : 1
- Certification : CSA Std. C22.2 No. 235, UL 489
