Product Info
- Manufacturer:Eaton, Cutler Hammer
- Sub-Category:Molded Case
Description
FAZ-C1.5/1-NA-SP
FAZ-C1.5/1-NA-SP is an Eaton miniature circuit breaker designed for branch circuit protection with a 1.5 amp rating and C curve trip characteristic.This UL 489 industrial supplementary protector features a single pole, 277 VAC voltage rating, and a 10 kA interrupting capacity. It mounts on a 35mm DIN rail and provides thermal magnetic trip protection suitable for medium inrush current applications. The breaker is UL and CSA certified, ensuring compliance with industry safety standards.
- Amperage: 1.5 A
- Voltage: 277 VAC
- Poles: 1
- Mounting: 35mm DIN rail
- Interrupting Rating: 10 kA
- Trip Curve: C Curve (5-10x In)
- Series: FAZ
- UL 489 and CSA certified
- Thermal magnetic trip unit
- Suitable for medium inrush current
Specifications
- Part Number: FAZ-C1.5/1-NA-SP
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAZ Series
- Type : FAZ
- Voltage : 480
- Amperage : 1.5
- Phase : 1
- Poles : 1
- AIC rating : 10kA@480/277V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Protection : Thermal Magnetic
Product Data
- UPC : 01508163663
- GTIN : 04015081636631
- Dimensions : 0.7 in x 4.13 in x 2.97 in (Length/Depth x Height x Width)
- Weight : 1
