2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FAZ-B50/3
FAZ-B50/3 is a 3-pole thermal magnetic circuit breaker from Eaton designed for reliable circuit protection with a 50 ampere rating and 277/480VAC voltage capacity.FAZ-B50/3 features a B curve trip unit, 10kA interrupting rating at 240VAC, and is DIN rail mountable, making it suitable for industrial and commercial applications requiring UL 489 certification.
- Key Specifications
- Current Rating: 50 Amps
- Voltage Rating: 277/480 VAC
- Number of Poles: 3
- Trip Curve: B Curve
- Interrupting Rating: 10kA @ 240 VAC
- Breaker Type: Thermal Magnetic
- Mounting Type: 35mm DIN Rail
- Standards: UL 489 Certified
- Actuator Type: Lever
- Series/Frame: FAZ
Specifications
- Part Number: FAZ-B50/3
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAZ Series
- Type : FAZ
- Voltage : 4
- Amperage : 50
- Phase : 3
- Poles : 3
- AIC rating : 10kA@277/480V
- Connection : Feed-Thru
- Functions : LI - Long Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 01508278852
- GTIN : 04015082788520
- Country of Origin : Germany
- Dimensions : 2.07 in x 2.07 in x 2 in (Length/Depth x Height x Width)
- Weight : 0.8
