FAZ-B5/3-NA - Eaton 5A 277/480V 3-Pole Thermal Magnetic Circuit Breaker B Curve

FAZ-B5/3-NA

FAZ-B5/3-NA is a 3-pole thermal magnetic circuit breaker from Eaton designed for branch circuit protection with a 5 amp rating and 277/480 VAC voltage capability.This Eaton FAZ-B5/3-NA miniature circuit breaker features a B curve trip characteristic suitable for applications with low inrush current, a 10 kA interrupt rating at 277/480 VAC, and screw terminal connections. It is UL 489 and CSA certified, designed for DIN rail mounting, and provides reliable protection for industrial and commercial electrical systems.

• Amperage Rating: 5 A
• Voltage Rating: 277/480 VAC
• Number of Poles: 3
• Trip Curve: B Curve (thermal magnetic)
• Interrupt Rating: 10 kAIC (UL 489)
• Mounting Type: DIN Rail
• Terminal Type: Screw
• Certifications: UL 489, CSA C22.2 No. 235
• Trip Unit Type: Thermal Magnetic
• Frequency: 50-60 Hz
• Product Dimensions: Approx. 4.13" H x 2.97" W x 2.1" D
• Application: Suitable for low inrush current loads

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAZ-B5/3-NA
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : FAZ Series
• Type : FAZ-NA
• Voltage : 1
• Amperage : 5
• Phase : 3
• Poles : 3
• AIC rating : 10kA@277/480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 01508129666
• GTIN : 04015081296668
• Country of Origin : Germany
• Dimensions : 2.1 in x 4.13 in x 2.97 in (Length/Depth x Height x Width)
• Weight : 1
