Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FAZ-B4/3
FAZ-B4/3 is a 3 pole, 4 amp miniature circuit breaker from Eaton designed for industrial supplementary protection.This Eaton FAZ-B4/3 circuit breaker features a B curve thermal magnetic trip unit, suitable for low inrush current applications. It supports a voltage rating of 480Y/277 VAC and 96 VDC, with a 10kA interrupting rating. The breaker is DIN rail mountable and UL 1077 listed for industrial supplementary protection.
- Key Specifications
- Amperage: 4 Amps
- Poles: 3 Pole
- Voltage Rating: 480Y/277 VAC, 96 VDC
- Trip Curve: B Curve (thermal magnetic)
- Interrupt Rating: 10 kA @ 480Y/277 VAC
- Mounting Type: DIN Rail Mount
- Series/Frame: FAZ
- Certifications: UL 1077 Listed
- Application: Industrial supplementary protection
- Part Number: FAZ-B4/3
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAZ Series
- Type : FAZ
- Voltage : 480
- Amperage : 4
- Phase : 3
- Poles : 3
- AIC rating : 10kA@277/480V
- Connection : Feed-Thru
- Functions : LI - Long Time and Instantaneous
- Protection : Thermal Magnetic
- UPC : 01508278839
- GTIN : 04015082788391
- Dimensions : 2.07 in x 2.07 in x 2 in (Length/Depth x Height x Width)
- Weight : 0.79
