Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FAZ-B32/3-NA
FAZ-B32/3-NA is a 32 amp, 3-pole thermal magnetic circuit breaker from Eaton designed for industrial and commercial applications.This Eaton FAZ-NA series miniature circuit breaker features a B curve trip characteristic suitable for low inrush current applications. It supports a rated operational voltage of 277/480 VAC and a rated current of 32A. The breaker has an interrupting capacity of 10 kAIC (UL/CSA) and 14 kAIC, with a 35mm DIN rail mounting type. It is UL 489 and IEC 60947-2 certified, providing reliable protection with a thermal magnetic trip unit.
- Key Specifications
- Amperage: 32 A
- Voltage Rating: 277/480 VAC
- Poles: 3
- Trip Curve: B (thermal magnetic)
- Interrupting Capacity: 10 kAIC UL/CSA, 14 kAIC
- Mounting Type: 35mm DIN rail
- Series/Frame: FAZ-NA
- Certifications: UL 489, IEC 60947-2
- Current Limiting: Yes
- Application: Industrial and commercial branch circuit protection
- Part Number: FAZ-B32/3-NA
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAZ Series
- Type : FAZ-NA
- Voltage : 480
- Amperage : 32
- Phase : 3
- Poles : 3
- AIC rating : 10kA@277/480V
- Connection : Feed-Thru
- Functions : LI - Long Time and Instantaneous
- Protection : Thermal Magnetic
- UPC : 01508129677
- GTIN : 04015081296774
- Dimensions : 2.1 in x 3 in x 2.25 in (Length/Depth x Height x Width)
- Weight : 0.9
